SCALE INSTRUCTIONS
SCALE INSTRUCTIONS
● Overload is strictly prohibited.
● Keep good weighing habits when using. During the weighing process, try to place it in the middle of the forklift to allow the four sensors of the forklift to balance the force. Do not place pallets and other goods on the front of the fork for weighing, which will cause uneven force on the sensor and affect the life of the forklift scale.
● During the operation, it cannot be lowered quickly under heavy load, so as not to damage the hydraulic cylinder and weighing main parts.
● In the heavy load state, the forklift scale cannot be pushed and transported, and the hydraulic device cannot be raised.
● It is forbidden to perform arc welding on forklift scales. Do not use sensors to become part of the arc welding circuit.
● Although the forklift scale instrument has been treated with waterproof, etc., it must also be protected from exposure to sunlight and water during application. It is not recommended to be in the open air for too long.
● The front and rear casters use polyurethane material as standard. Avoid using it on hot ground to avoid damage.
●non-special explosion-proof products, please do not apply to flammable and explosive occasions. Explosion-proof products should also be careful not to be subjected to strong impact when applied in flammable and explosive situations, so as to avoid sparks due to impact.
● When charging the forklift scale, please keep away from flammable and explosive places.
FORKLIFT SCALE MATERIALS
FORKLIFT SCALE MATERIALS
● The forklift body of our factory is made of full carbon steel, with high hardness, good strength, ruggedness, long-term reliability, and not afraid of impact. Full name is shot blasting, electrostatic spraying, stable storage at normal temperature, smooth and bright surface, beautiful appearance and strong anti-corrosion ability.
● There are two kinds of wheels: nylon and polyurethane. Nylon steering wheels and transport wheels are suitable for reducing the transportation height, have high resistance to chemicals, and leave no traces during transportation. Polyurethane wheels are suitable for light flooring. They leave no traces when loaded and have very low noise and are very durable.
● The instrument has A12E, A23P, T8, A9P, etc. to choose from, and the sensor has three types to choose from: wide measurement, Evergreen, and Keli. The measurement is accurate, the maximum range is 2T, and the minimum range is 500kg.
● Four all-alloy sensors are installed at four corners. Weigh the platen and sensor linkage mechanism to ensure that the platen is stable, not shaken, not warped, and not loosened for long-term use.
● Rechargeable sealed lead-acid battery with battery capacity of 6V4AH.
● The material of the fully-sealed lifting cylinder is excellent in quality and heat treatment. The main sealing parts of the cylinder are imported products. The steel tank is filled with high-quality hydraulic oil, which can ensure normal use at a temperature of -20 ° C-50 ° C.
